• Only six basic ranges cover pressures from 2 kPa to 40 MPa.
• 4 to 20 mA programmable current output with HART communication.
• Easily configurable and scalable up to 1:20, sensor zeroing.
• Accuracy of 0.1% in reference conditions and 0.25% FS over the entire ambient temperature range -20 to 80 °C.
• Stainless steel separating diaphragm.
• Robust aluminium housing with display.
• Can be reconfigured using built-in buttons, HARTConf configurator or HARTWinConf and standard HART modem.



   Links and documentation:

• Manual (En)
